Seiko LSWNH Series High & Long Arm Industrial Walking Foot Sewing Machine

High speed, compound feed and walking foot, Reverse stitch, Large Vertical Axis Hook (2.0 times) High and long arm lockstitch machine.

Models

• LSWNH-8BL-20 – Single Needle
• LSWNH-8BL-20-BTFL – Single needle, automatic back tack, automatic presser foot lift
• LSWNH-28BL-20 – Two Needle
• LSWNH-28BL-20-BTFL –  Two Needle, Automatic back tack, automatic presser foot lift.

Applications

• For sewing medium to heavy weight materials such as leather, Vinyl, Synthetics, laminated and coated materials
• Suitable for sewing tents, covers, sails, awnings, tarpaulins, automobile upholstery

Features:

• Standard equipment of long stitch (max 10mm) suitable for thick material and amount of alternative presser lift (max 6mm)
• Adoption of feed adjusting dial which eases determination process of stitch length
• Plain needle drop area/ adoption of open / close simplified face place which provides wide ranged movement of of sewn material.
• Advanced penetration required for sewing of thick material / adoption of large pulley (O.D 150mm) which enables the needle bar to be positioned properly.
• Built in bobbin winder makes it possible to wind the bobbin thread during sewing operation
• Large capacity hook (2.0 times / Automatic hook lubrication) minimised the times to replace the bobbin thread
• Safety Clutch prevents the hook from being damaged
• Available in ” Thick Thread Version” for heavier material.

For more information please see Seiko LSWNH
